RMS Co., Ltd. provides a wide range of thin film power resistors designed for power control, capacitor discharge, high-voltage, and industrial electronic applications. RMS solutions include high voltage film resistors, high-power capacitor discharge resistors, power metal film chip resistors, and power thin film resistors engineered for different resistance, power, mounting, and operating requirements.
Among the RMS resistor portfolio, the RQO, SMF, and TNP Series provide different film-based resistor technologies for engineers selecting components according to power capacity, resistance range, voltage conditions, tolerance, thermal characteristics, and mounting requirements.
What Are Thin Film Power Resistors?
Thin film power resistors are resistive components designed to provide controlled resistance while handling electrical power under specified operating conditions. Film-based resistor technologies can support stable electrical characteristics, compact configurations, and a broad range of resistance values depending on the construction and application.
In practical circuit design, engineers should evaluate more than nominal resistance. Power rating, resistance tolerance, voltage capability, temperature characteristics, thermal management, and mounting conditions can all influence resistor selection and long-term performance.
For high voltage film resistors, voltage capability and insulation characteristics become particularly important because the resistor must maintain stable electrical performance under elevated voltage conditions.
RQO Series High Power Capacitor Discharge Resistors
The RQO Series is designed for high-power capacitor discharge applications. The RQO15 model combines different resistive constructions to support a broad resistance range while providing a rated power of 10W.
Key Specifications – RQO15
- Rated Power: 10W
- Resistance Range:
- Ceramic Core (CC): 0.5Ω to 1.5kΩ
- Metal Oxide Film (MO): 0.3Ω to 10kΩ
- Glass Fiber Core (GC): 10Ω to 75kΩ
- Resistance Tolerance:
- R ≤ 1Ω: ±10%
- R > 1Ω: ±5%
- Temperature Range: -25°C to +155°C
- Temperature Coefficient: Max. ±490 ppm/°C
- Insulation Resistance: DC 500V, 20MΩ minimum
- Dielectric Withstanding Voltage: AC 1500V for 1 minute
These characteristics make the RQO Series suitable for capacitor discharge circuits where engineers need to consider resistance value, power handling, temperature behavior, and electrical insulation together.
SMF Series Power Metal Film Chip Resistors
The SMF Series consists of power metal film chip resistors designed for automatic surface mounting. RMS specifies a flameproof UL94V-0 molded package together with heat and humidity resistance, insulation performance, mechanical strength, and electrical stability.
Its compact surface-mount construction supports electronic assemblies where PCB space, automated mounting, and stable resistor performance are important design considerations.
Key Specifications
The SMF Series is available in multiple power configurations, including 2W and 3W models, with resistance values and tolerances depending on the selected model. RMS specifies tolerance options including ±1% and ±5%.
Applications listed by RMS include:
- Consumer electronics
- Computers
- Telecommunications equipment
- Control instruments
When selecting an SMF resistor, engineers should evaluate the required resistance value, rated power, working voltage, tolerance, and PCB mounting conditions for the specific application.
TNP Series Power Thin Film Resistors
The TNP Series represents RMS power thin film resistor solutions developed for power electronic applications requiring film-based resistance technology in higher-power configurations.
RMS offers multiple TNP configurations with different power and package options. The portfolio includes TNP50S and TNP100S TO-247 configurations, allowing engineers to evaluate suitable thin film power resistors according to resistance, power, mounting, voltage, and circuit requirements.
For applications involving elevated voltage conditions, engineers should also evaluate the resistor’s voltage capability, insulation requirements, thermal characteristics, and operating environment rather than selecting a component based only on resistance and wattage.
Key Engineering Considerations for Thin Film Power Resistors
Selecting the appropriate thin film power resistor requires evaluating several electrical and thermal parameters together.
Power rating indicates the electrical load the resistor is designed to handle under specified operating conditions, while resistance tolerance indicates how closely actual resistance corresponds to the nominal value.
Temperature characteristics are also important because changes in operating temperature can influence resistance behavior. Engineers should therefore consider temperature coefficient characteristics together with expected operating temperatures and thermal management conditions.
For high voltage film resistors, maximum working voltage, dielectric strength, insulation resistance, resistor construction, and circuit layout should also be evaluated. These factors become increasingly important in voltage control and other high-voltage applications.
In capacitor discharge applications, pulse and overload conditions may require additional consideration. RMS specifies characteristics such as short-time overload, moisture resistance, thermal shock, and load life for the RQO15 Series, giving engineers additional parameters for evaluating the resistor beyond nominal resistance and rated power.
Selecting the Right RMS Film Resistor
The appropriate resistor technology depends on the electrical and mechanical requirements of the application.
The RQO Series provides options for capacitor discharge applications requiring power handling and a broad resistance range. The SMF Series provides compact power metal film chip resistor solutions suitable for surface-mounted electronic assemblies. The TNP Series provides power thin film resistor options for applications requiring higher-power film resistor configurations.
Engineers evaluating thin film power resistors or high voltage film resistors should therefore compare resistance range, rated power, tolerance, voltage requirements, thermal conditions, and mounting method before selecting a specific RMS series.
RMS Thin Film and High Voltage Film Resistor Solutions
RMS offers resistor technologies for power, capacitor discharge, high-voltage, and industrial electronic applications.
Its portfolio of thin film power resistors, metal film chip resistors, capacitor discharge resistors, and related film resistor technologies enables engineers to evaluate different configurations according to their electrical, thermal, and mechanical requirements.
Rather than relying on a single resistor technology, RMS provides multiple series and configurations for different circuit and application requirements.
Meet RMS at electronica 2026 in Munich
RMS Co., Ltd. will participate in electronica 2026, taking place from November 10 to 13, 2026, at Messe München in Munich, Germany. The international electronics trade fair covers technologies, components, products, and solutions across the electronics industry, including passive components and power electronics.
Passive Components are presented in Halls A6 and B6, with resistors included among the product categories. The exhibition therefore provides a relevant setting for RMS to introduce its resistor technologies to engineers, buyers, and other electronics industry professionals.
Visitors can meet RMS at Hall A6, Booth 418 to learn more about its resistor portfolio, including thin film power resistors and other resistor solutions for high-voltage, capacitor discharge, power, and industrial electronic applications. Visitors can also discuss specific application requirements and suitable RMS resistor technologies with the company.
Event Information
– Event: electronica 2026
– Date: November 10–13, 2026
– Venue: Messe München, Munich, Germany
– Exhibition Area: Passive Components
– RMS Booth: Hall A6, Booth 418
